X-ERA by ImageWorks
2D X-era produces a crisp, high-quality image with uncompromised clarity, revealing a finer level of detail on every capture. It reduces the need for retakes and minimizes the time spent on post-capture image enhancement. Superior image quality for a confident diagnosis X-era is designed with a direct CMOS sensor and unique image construction technology, enabling it to produce a sharper image. Combines the finest details of more than 3,600 single high resolution images to provide a sharp and high-definition scan. (16 bit 65,536 grading)
Exceptionally sharp 3D imaging to meet the needs of every doctor X-era provides fast 3D scanning with brilliant results. It captures pristine, high-definition 3D images to accommodate a comprehensive range of clinical needs. In addition, we've shortened the scan time, reducing the burden on patients and making it easier for you to incorporate 3D imaging into daily practice.
Design Philosophy Even with X-era's largest FOV size (Φ 156 mm × 79 mm), a full 360-degree 3D scan takes as little as 12 seconds. High-speed scans reduce the risk of patient movement, thus minimizing motion artifacts in the image. 360° CT scan in just 12 seconds̶with our largest FOV sec. scan X-era has been carefully designed to benefit both doctors and patients. Regardless of the scanning area or diagnosis, capturing images is quick, easy and comfortable, thanks to exclusive design features. These features help to reduce the burden on both doctor and patient.
2D X-era produces a crisp, high-quality image with uncompromised clarity, revealing a finer level of detail on every capture. It reduces the need for retakes and minimizes the time spent on post-capture image enhancement. Superior image quality for a confident diagnosis X-era is designed with a direct CMOS sensor and unique image construction technology, enabling it to produce a sharper image. Combines the finest details of more than 3,600 single high resolution images to provide a sharp and high-definition scan. (16 bit 65,536 grading)
Exceptionally sharp 3D imaging to meet the needs of every doctor X-era provides fast 3D scanning with brilliant results. It captures pristine, high-definition 3D images to accommodate a comprehensive range of clinical needs. In addition, we've shortened the scan time, reducing the burden on patients and making it easier for you to incorporate 3D imaging into daily practice.
Design Philosophy Even with X-era's largest FOV size (Φ 156 mm × 79 mm), a full 360-degree 3D scan takes as little as 12 seconds. High-speed scans reduce the risk of patient movement, thus minimizing motion artifacts in the image. 360° CT scan in just 12 seconds̶with our largest FOV sec. scan X-era has been carefully designed to benefit both doctors and patients. Regardless of the scanning area or diagnosis, capturing images is quick, easy and comfortable, thanks to exclusive design features. These features help to reduce the burden on both doctor and patient.
2D X-era produces a crisp, high-quality image with uncompromised clarity, revealing a finer level of detail on every capture. It reduces the need for retakes and minimizes the time spent on post-capture image enhancement. Superior image quality for a confident diagnosis X-era is designed with a direct CMOS sensor and unique image construction technology, enabling it to produce a sharper image. Combines the finest details of more than 3,600 single high resolution images to provide a sharp and high-definition scan. (16 bit 65,536 grading)
Exceptionally sharp 3D imaging to meet the needs of every doctor X-era provides fast 3D scanning with brilliant results. It captures pristine, high-definition 3D images to accommodate a comprehensive range of clinical needs. In addition, we've shortened the scan time, reducing the burden on patients and making it easier for you to incorporate 3D imaging into daily practice.
Design Philosophy Even with X-era's largest FOV size (Φ 156 mm × 79 mm), a full 360-degree 3D scan takes as little as 12 seconds. High-speed scans reduce the risk of patient movement, thus minimizing motion artifacts in the image. 360° CT scan in just 12 seconds̶with our largest FOV sec. scan X-era has been carefully designed to benefit both doctors and patients. Regardless of the scanning area or diagnosis, capturing images is quick, easy and comfortable, thanks to exclusive design features. These features help to reduce the burden on both doctor and patient.
Panoramic
----------------------------------
- Sensor - Direct CMOS Sensor
- Grading - 16 Bit (65,536 Grading)
- Exposure Time - 7, 12 sec. (Panoramic)
- 1.7 sec. x4 (TMJ)
- Magnification Factor - 1.3-1.4 (Panoramic Exposure, TMJ Exposure)
- Pixel - 100 um isotropic/pixel, 1,510x3,341 pixel (Panoramic)
Cephalometric
----------------------------------
Sensor - Direct CMOS Sensor
- Exposure time - 8 Sec./12 sec (PA)
- 10 sec/15 sec (LA)
- 8 sec/12 sec (Carpus)
- Magnification Factor 1.1
- Pixel - 2605px X 2266px (LA)
- 2097px X 2266px (PA/Carpus)
3D
-----------------------------------
- Sensor - CMOS Sensor
- Exposure Size
- Voxel size Xera MF
φ44mm×64mm (61mm) 90μｍ
φ80mm×79mm (72mm) 150μｍ
φ110mm×79mm (69mm) 180μｍ
φ156mm×79mm (65mm) 230μｍ Xera NF
φ44mm×H64mm (61mm) 90μｍ
φ85mm×H64mm (58mm) 150μｍ
Exposure time
Standard .. 12 sec. (same for all exposure size)
High def... 16 – 20 sec.
Common Spec.
------------------------------------
- Tube Voltage - 70 - 90kV
- Tube Current - 2.0-4.0 mA
- Power Supply - AC100-120V±10%
- AC220V-240V±10%
- Total Filtration - 2.5mm Aluminum
- Operation Condition
Temporary - 10 to 40°C (50 to 104°F)
Relative Humidity - 30 to 75% (no condensation)
Atmospheric Pressure - 700 to 1060 hPa
*Horizontal pixel may change by the adjustment of layer
**To Install, the equipment needs to be wall-mounted**
